High Capacity Linear Vibrating Screen Spice Screening Machine For
Sale
LINEAR VIBRATING SCREEN INTRODUCTION
Linear vibrating screen is a commonly closed light vibrating
screening equipment, it put the vibrating motor excitation as the
vibration source, making the material on screen surface was leaps
straight forward movement, the material flow from the feeder into
the screening machine evenly, via multi-screen, there will be
several specifications materials.
LINEAR VIBRATING SCREEN APPLICATION
Suitable for particle size is 0.074-5mm, moisture content is less
than 70%, non-sticky variety of dry powdered material screening,
maximum feed particle size is generally not more than 10mm. This
series of vibrating screen can be also used to liquid filtration
screening operations, it is also used for sewage treatment, and can
be also used for larger particles of coal materials screening, when
handling large material, the screen thickness required to thicken,
Electric power demand increased, and make the punching sieve as
mesh.
It is widely used in plastics, abrasives, chemicals,
pharmaceuticals, building materials, food, carbon, fertilizer and
other industries.
LINEAR VIBRATING FEATURE
1) Stable and reliable, low consumption, low noise, long life,
vibration steady, high screening efficiency .
2) It can be single or multi-use, screen frame is generally wooden
structure, the screen frame can be made of steel structure if there
is higher production requirements. The part connect with material
can be made of stainless steel if the material is corrosive.
3) Good sealing performance, minimal dust spilling .
4) Low energy consumption, low noise, long life screen.
5) High screening precision, large capacity, simple structure .
6) Fully enclosed structure, automatic nesting, it’s better
suitable for pipeline operations.
7) Each part of the sieve body is made of rolled steel plates and
profiles welded together (some parts are connected with bolted)
overall stiffness is good, solid and reliable.
LINEAR VIBRATING SCREEN PARAMETERS
| Model | SZF-525 | SZF-530 | SZF-1020 | SZF-1030 | SZF-1230 | SZF-1235 | SZF -1530 | SZF-1540 |
| DN(m) | 0.5*2.5 | 0.5*3 | 1*2 | 1*3 | 1.2*3 | 1.2*3.5 | 1.5*3 | 1.5*4 |
| Material diameter(mm) | 0.074-10 | 0.074-10 | 0.074-10 | 0.074-10 | 0.074-10 | 0.074-10 | 0.074-10 | 0.074-10 |
| Vibration/min | 960 | 960 | 960 | 960 | 960 | 960 | 960 | 960 |
| Screen surface Angle | 0°-7° | 0°-7° | 0°-7° | 0°-7° | 0°-7° | 0°-7° | 0°-7° | 0°-7° |
| Amplitude | 3-7 | 3-7 | 3-7 | 3-7 | 3-7 | 3-7 | 3-7 | 3-7 |
| Number of plies | 1-6 | 1-6 | 1-6 | 1-6 | 1-6 | 1-6 | 1-6 | 1-6 |
| Power(KW) | 2*0.37 | 2*0.55 | 2*0.75 | 2*1.1 | 2*1.1 | 2-1.5 | 2*2.2 | 2*2.2 |
LINEAR VIBRATING PICTURES
LINEAR VIBRATING SCREEN PACKAGING AND SHIPPING
We will pack the linear vibrating screen by wooden case and then we
can ship it by air, by railway, by sea or by truck. You can choose
what you need.
ABOUT US
Zhengzhou Generate Machinery Co.,Ltd. is the professional provider
of vibrating, conveying and lifting equipments. And our main
products are various kinds of vibrating sieves and conveyors, such
as rotary vibrating sieves, test sieves, belt conveyors, modular
conveyors, roller conveyors, slat conveyors, bucket elevators and
so on.
We have rich sales experience exporting to Europe, USA, Middle
east, Southeast Asia etc for more than 30 years. We have rich
design, manufacturing, debugging experience and our professional
designer can meet any of your special requirements.
If you have any question, please do not hesitate to ask us.
Mobile/WhatsApp/Wechat: (86) 15290830135
Email: info@zzgenerate.com
Skype: Linda15290830135
Contact: Linda
